Description
Working Principle
Based on the differential density of steam and liquid.
Features
- Valve body and bonnet are made of cast steel, forged steel.
- All internal parts are made of stainless steel, whichimproves the service life of the steam trap.
- Adopting double balanced valve seat,with an ultra long service life.
- Built-in air exhaust valve to prevent steam lock.
- Water seal design, no original steam leakage.
- Choose different capacity curves according to the differential pressure.
- Back pressure rate is as high as 95%.
- Drain plug is designed at the bottom of the steam trap to ensure that the internal water will be drained, to prevent floating ball from freezing damage in cold weather.
