Description
Working Principle
Based on the density of vapor and liquid.
Features
- The valve body and bonnet are made of cast steel/forged steel.
- All internal parts are made of stainless steel, and the wear allowance has been fully considered in the design of movable parts, which improves the service life of the trap.
- Special flow channel design to achieve zero water hammer.
- Patented flexible closing system and micron-level precision closing system double guarantee no steam leakage and long service life.
- Built-in air exhaust valve to prevent steam lock.
- The independent filter makes the trap work in a clean environment.
- Choose different displacement curves according to the pressure.
- The back pressure rate is as high as 95%
- The drain plug is designed at the bottom of the trap to ensure that the internal water is removed after stopping, to prevented floating ball from freezing in cold weather.
