ANSI STANDARD BELLOWS SEALED GLOBE VALVE

ANSI STANDARD BELLOWS SEALED GLOBE VALVE Data Dimension

ANSI Standard Bellows Sealed Globe Valve

Bellows sealed element.The key part metal bellows is the connection between bonnet and stem by automatic roll welding. It can keep the stem part zero leakage.
Benefited from the cone and streamline shape design, the disc has reliable sealing performance and longer service life.

ANSI Standard Bellows Sealed Globe Valve

Description

Description

Product Advantage

Bellows sealed element. The key part metal bellows is the connection between bonnet and stem by automatic roll welding. It can keep the stem part zero leakage.
Benefited from the cone and streamline shape design, the disc has reliable sealing performance and longer service life.
Double seal design (bellows+packing). Bellows and packing can prevent from leakage and provide excellent sealing performance.
Grease nipple. It can directly lubricate the stem, nut and sleeve.
Ergonomic hand wheel. It provides longer service life and easier operation.

Specifications

Design standard: ASME B16.34
Face to face dimension: ASME B16.10
Flange ends: ASME B16.5
Test & inspection: API598

Application

Thermal oil, Steam, Hot and cold water, Fatty acids, Ammonia, Natural gas, etc.

Advantages of VMV Bellows

Quality Control

Data Dimension Table

Material	NPS	150LB			300LB
Material	NPS	L	W	H≈	L	W	H≈
A105	1/2＂	108	Φ120	240	152	Φ140	240
	3/4＂	117	Φ120	240	178	Φ140	240
	1＂	127	Φ140	256	203	Φ160	256
	1 1/4＂	140	Φ140	267	216	Φ160	267
	1 1/2＂	165	Φ160	325	229	Φ180	325
	2＂	203	Φ200	348	267	Φ200	348
WCB	2＂	203	Φ200	315	267	Φ220	328
	2 1/2	216	Φ220	330	292	Φ250	355
	3＂	241	Φ240	380	318	Φ300	414
	4＂	292	Φ300	405	356	Φ350	433
	5＂	356	Φ350	455	400	Φ400	452
	6＂	406	Φ400	513	444	Φ450	545
	8＂	495	Φ450	683	559	Φ600	725
	10＂	622	Φ550	736	622	Φ600	798
	12＂	698	Φ600	820	711	Φ600	933
	14＂	787	–	–	838	–	–
	16＂	914	–	–	864	–	–
